ACTIVAR—P7系统：400V、串7%电抗，防止5次谐波的谐振放大
| 系统代码
|
输出 (KVAR)
|
每步输出(KVAR)
|
比例
|
总步数
|
外形尺寸W*D*H(mm)
|
| AR125/5-2-400.50-P7
|
125
|
25
|
1:2:2
|
5
|
800*600*2100
|
| AR150/5-2-400.50-P7
|
150
|
30
|
1:2:2
|
5
|
800*600*2100
|
| AR200/5-2-400.50-P7
|
200
|
40
|
1:2:2
|
5
|
800*600*2100
|
| AR250/5-2-400.50-P7
|
250
|
50
|
1:2:2
|
5
|
800*600*2100
|
| AR300/5-2-400.50-P7
|
300
|
60
|
1:2:2
|
5
|
800*600*2100
|
| AR350/7-4-400.50-P7
|
350
|
50
|
1:2:4
|
7
|
800*600*2100
|
| AR420/7-2-400.50-P7
|
420
|
60
|
1:2:2
|
7
|
1000*600*2100
|
| AR480/6-1-400.50-P7
|
480
|
80
|
1:1:1
|
6
|
1600*600*2100
|
| AR550/11-2-400.50-P7
|
550
|
50
|
1:2:2
|
11
|
1600*600*2100
|
| AR600/6-1-400.50-P7
|
600
|
100
|
1:1:1
|
6
|
1600*600*2100
|
| AR660/11-2-400.50-P7
|
660
|
60
|
1:2:2
|
11
|
1600*600*2100
|
| AR720/6-1-400.50-P7
|
720
|
120
|
1:1:1
|
6
|
1600*600*2100
|
| AR900/9-1-400.50-P7
|
900
|
100
|
1:1:1
|
9
|
2400*600*2100
|
| AR1080/9-1-400.50-P7
|
1080
|
120
|
1:1:1
|
9
|
2400*600*2100
|
| AR1200/12-1-400.5-P7
|
1200
|
100
|
1:1:1
|
12
|
3200*600*2100
|
| AR1440/12-1-400.5-P7
|
1440
|
120
|
1:1:1
|
12
|
3200*600*2100
|
ACTIVAR—P14系统：400V、串14%电抗，防止3次谐波的谐振放大
| 系统代码
|
输出 (KVAR)
|
每步输出(KVAR)
|
比例
|
总步数
|
外形尺寸W*D*H(mm)
|
| AR200/5-2-400.50-P14
|
200
|
40
|
1:2:2
|
5
|
800*600*2100
|
| AR250/5-2-400.50-P14
|
250
|
50
|
1:2:2
|
5
|
800*600*2100
|
| AR300/5-2-400.50-P14
|
300
|
60
|
1:2:2
|
5
|
800*600*2100
|
| AR360/3-1-400.50-P14
|
360
|
120
|
1:1:1
|
3
|
800*600*2100
|
| AR480/6-1-400.50-P14
|
480
|
80
|
1:1:1
|
6
|
1600*600*2100
|
| AR550/11-2-400.50-P14
|
550
|
50
|
1:2:2
|
11
|
1600*600*2100
|
| AR600/6-1-400.50-P14
|
600
|
100
|
1:1:1
|
6
|
1600*600*2100
|
| AR660/11-2-400.50-P14
|
660
|
60
|
1:2:2
|
11
|
1600*600*2100
|
| AR720/6-1-400.50-P14
|
720
|
120
|
1:1:1
|
6
|
1600*600*2100
|
| AR900/9-1-400.50-P14
|
900
|
100
|
1:1:1
|
9
|
2400*600*2100
|
| AR1080/9-1-400.50-P14
|
1080
|
120
|
1:1:1
|
9
|
2400*600*2100
|
| AR1200/12-1-400.5-P14
|
1200
|
100
|
1:1:1
|
12
|
3200*600*2100
|
| AR1440/12-1-400.5-P14
|
1440
|
120
|
1:1:1
|
12
|
3200*600*2100
|
|
